Design Criteria of Anstorm Power Control Cabinet
1. Mechanical Structure Compliance:
The Anstorm Power Control Cabinet meets the performance requirements of the electrical products it houses, providing the necessary electromechanical interfaces.
2. Component Installation Support:
The electric power box provides secure fastening, locking, and limiting mechanisms for the installation of components such as pipes, enclosures, and drawers.
3. Ease of Electrical Component Installation:
It offers convenient installation for electrical devices, components, and accessories, specifying the locations, installation methods, and precautions in the cabinet’s documentation.
4. Structural Rigidity and Strength:
The overall structure of the Control Cabinet is designed with sufficient rigidity and strength to meet the installation, commissioning, and operational requirements of devices,
components, wiring, and accessories, as well as the requirements for lifting, handling, and cabinet assembly after the system is assembled.
5. Durability Against Mechanical, Electrical, and Thermal Stress:
The cabinet’s shell and structural parts are capable of withstanding mechanical, electrical, and thermal stresses during product operation without compromising performance.
6. Engineering Plastic Components:
Components made from engineering plastics in the Cabinet are designed with thermal stability, anti-aging properties, and flame resistance.
7. Environmental Protection Compliance:
Anstorm Power Control Cabinet meets environmental protection requirements for the equipment it houses.
8. Thermal Management and Protection Features:
The cabinet is equipped with heat dissipation, thermal insulation, dust protection, shielding, grounding, and vibration-damping features that ensure optimal functionality.
9. Ergonomic Design:
The design takes ergonomics into account to ensure ease of use and accessibility.
10. Manufacturing Process Considerations:
The design of the Power Control Cabinet fully considers manufacturability, ensuring efficient production.
11. Safety Compliance:
The design meets safety requirements, including protection against electric shock, mechanical hazards, fire hazards, and shell protection. Fire isolation is provided as per user requirements.
12. Thermal Dissipation:
Incorporates appropriate heat dissipation measures based on the product’s thermal characteristics.
13. Environmental Awareness Design:
The Power Integrated Control Cabinet follows environmentally conscious design principles.
